(IS 1237 — Anti-Skid Chequered Tiles)

Mechanical testing of chequered cement concrete tiles — verifying transverse strength, water absorption, abrasion resistance, skid resistance and dimensional accuracy per IS 1237 for staircase and outdoor use.

Overview

What is the Chequered Cement Concrete Tile Testing?

Chequered Cement Concrete Tiles are anti-skid floor tiles with a raised pattern (chequer, diamond or coin) moulded into the top surface — providing slip resistance for staircases, platforms, factory floors, bus stands, railway platforms and outdoor pavements. They are tested per IS 1237 with additional skid resistance verification.

At Global Lab, chequered tile testing covers all IS 1237 requirements — transverse breaking strength, water absorption, abrasion resistance, dimensional tolerances — plus specific anti-skid pattern assessment. Results confirm suitability for wet areas, outdoor applications and industrial facilities where slip resistance is a safety requirement.

IS 1237 Compliance

All standard IS 1237 mechanical tests conducted plus pattern assessment.

Skid Resistance Assessment

Surface profile and chequer pattern depth measured for anti-skid effectiveness.

Transverse Breaking Strength

Minimum 2000N per IS 1237 — same as standard cement tile.

Water Absorption ≤10%

Critical for outdoor and wet area anti-skid tile applications.

NABL Certified Reports

All results on NABL-accredited letterhead with IS 1237 compliance.

Outdoor & Wet Area Focus

All testing oriented to verify suitability for outdoor and wet conditions.

Test in Action

Chequered Cement Concrete Tile Testing — Site Images

Chequered Pattern Depth Measurement

Transverse Breaking Strength Test

Water Absorption After 24-Hour Immersion

Test Procedure

How the Chequered Cement Concrete Tile Testing is Conducted

1

Sample Collection

12 chequered tiles selected per IS 1237 sampling from consignment.
2

Dimensional & Pattern Check

All dimensions measured. Pattern depth and uniformity assessed.
3

Water Absorption

6 tiles tested for 24-hour water absorption per IS 1237.
4

Transverse Breaking Strength

6 tiles tested in three-point bending per IS 1237.
5

Abrasion & Report

Abrasion resistance tested. IS 1237 compliance assessed. NABL report within 28 days.

Standards & Specifications

Applicable Test Standards

Standard	Title	Scope	Type
IS 1237	Cement Concrete Flooring Tiles — Specification	Chequered Tile	Indian Standard
IS 1122	Method of Test for Determination of Specific Gravity and Water Absorption	Water Absorption	Indian Standard
IS 2114	Code of Practice for Laying In-Situ Terrazzo Floor Finish	Floor Finish Reference	Indian Standard
BS EN 13748-1	Terrazzo Tiles for Internal Use	European Reference	British Standard

Applications

Where is the CAPO Test Used?

Railway platform and bus stand chequered tile acceptance testing for Indian Railways

Factory floor and industrial area anti-skid tile quality control

Staircase chequered tile compressive strength and abrasion verification

Municipal footpath and outdoor pavement anti-skid tile procurement testing

Manufacturer quality certification for IS 1237 chequered tile compliance

Hospital and public building wet area anti-skid floor tile acceptance

Why Choose Global Lab

Our Advantages

NABL Accredited ReportsLegally valid IS 1237 compliance certificates for all project requirements.

Railway Accepted ReportsExperienced in anti-skid tile testing for Indian Railways platform projects.

Pattern Depth AssessmentChequer pattern depth measured alongside standard IS 1237 tests.

Fast 28-Day ReportComplete IS 1237 test suite within 28 days.

Pan-India CoverageTesting at all 7 NABL-accredited lab locations.

Combined Tile PackageChequered + Cement + Marble tile testing offered together.
